The features of LCD are as follows
* Display mode :STN/Yellow-Green/Transflective/Positive
* Controller/driver IC : SPLC780D1-001 :
* Display format :20x4 Characters
* Interface Input Data : 8 Bit
* Driving Method : 1/16Duty, 1/5Bias
* Viewing Direction : 6 O’clock
* Backlight : LED/bottom(Y-G)
* Sample NO. : C2004A0SBY6B-A0
For reference only. For design purposes, please use the specifications in the datasheet.
Physical Characteristics
| |
Module Overall |
Viewing Area |
Active Area |
| |
width |
height |
depth |
width |
height |
width |
height |
| millimeters |
77 |
47 |
14.2 |
60 |
22.2 |
55.12 |
17.56 |
| inches |
3.03 |
1.85 |
0.56 |
2.36 |
0.87 |
2.17 |
0.69 |
| |
Character Size |
Character Pitch |
Dot Size |
Dot Pitch |
| |
width |
height |
width |
height |
width |
height |
width |
height |
| millimeters |
2.3 |
4.03 |
2.78 |
4.51 |
0.42 |
0.46 |
0.47 |
0.51 |
| inches |
0.09 |
0.16 |
0.11 |
0.18 |
0.02 |
0.02 |
0.02 |
0.02 |
Optical Characteristics
| Display Addressing |
GlassType/Glass Color |
Polarizer |
View Direction |
| Passive |
STN/Yellow-Green |
Transflective |
6:00 |
| Backlight Color |
Backlight Type |
Mode |
| Yellow-Green |
LED |
Positive |
| Absolute maximum ratings |
Electrical characteristics |
| Supply Voltage For Lggic(V) |
-0.3~7.0 |
Logic Supply Voltage（V） |
5 |
| Supply Voltage For LCD Drive(V) |
VDD-10~VDD+0.3 |
LCD Drive（V） |
4.8 |
| Input Voltage(V) |
-0.3~VDD+0.3 |
Current Consumption(mA) |
1.39 |
| Backlight |
| Forward Current(mA) |
15 |
Forward Voltage(V) |
4.2 |
| Reverse Voltage(V) |
5 |
Average Luminous Intensity(cd/m2) |
80 |
| Power Dissipation(mW) |
1500 |
Peak emission wavelength(nm) |
570 |
Environmental
| |
Operating Temperatures |
Storage Temperatures |
| |
min |
max |
min |
max |
| Celsius |
-20° |
70° |
-25° |
75° |
| Farenheit |
-4° |
158° |
-13° |
167° |
| Humidity |
| |
min |
max |
| Non-condensing |
0 |
90% |
