The features of LCD are as follows
* Display mode : FSTN/Positive/Transflective
* Drive IC :ST7529-G
* Display format : 240X160 Dots
* Interface Input Data : 16-Bit
* Driving Method : 1/160duty, 1/12bias
* Viewing Direction : 6O’clock
* Backlight : LED White
*Sample NO. :G2416A3FSW1G-A0_01/20110114
For reference only. For design purposes, please use the specifications in the datasheet.
Physical Characteristics
| Column Dots x Row Dots |
240*160 |
| |
Module Overall |
Viewing Area |
Active Area |
| |
width |
height |
depth |
width |
height |
width |
height |
| millimeters |
77.42 |
61 |
5.3 |
73.42 |
48 |
67.42 |
44.94 |
| inches |
3.05 |
2.40 |
0.21 |
2.89 |
1.89 |
2.65 |
1.77 |
| |
Dot Size |
Dot Pitch |
| |
width |
height |
width |
height |
| millimeters |
0.261 |
0.261 |
0.281 |
0.281 |
| inches |
0.010 |
0.010 |
0.011 |
0.011 |
Optical Characteristics
| Display Addressing |
GlassType |
Polarizer |
View Direction |
| Passive |
FSTN |
Transflective |
6:00 |
| Absolute maximum ratings |
Electrical characteristics |
| Supply Voltage For Lggic(V) |
-0.5~4.0 |
Logic Supply Voltage（V） |
3 |
| Supply Voltage For LCD Drive(V) |
-0.5~18 |
LCD Drive（V） |
15.7 |
| Input Voltage(V) |
-0.5~VDD+0.5 |
Current Consumption(mA) |
1.86 |
| Backlight |
| Forward Current(mA) |
60 |
Forward Voltage(V) |
3.1 |
| Reverse Voltage(V) |
5 |
Average Luminous Intensity(cd/m2) |
150 |
| Power Dissipation(mW) |
192 |
|
Environmental
| |
Operating Temperatures |
Storage Temperatures |
| |
min |
max |
min |
max |
| Celsius |
-10° |
60° |
-20° |
70° |
| Farenheit |
14° |
140° |
-4° |
158° |
| Humidity |
| |
min |
max |
| Non-condensing |
0 |
90% |
